April 2017
2-18
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
003-320 to 003-343
Launch Issue
Status Indicator RAPs
003-320 to 003-343 IISS-ESS Communication Fail RAP
003-320 IISS sending error detected by the controller. An abnormal parameter is set as the
argument for the send function.
003-321 IISS sending error detected by the controller. After commands were sent twice from
the controller, the controller could not receive acknowledgment from the IISS.
003-322 IISS sending error detected by the controller. After commands were sent twice from
the controller, the controller could not receive acknowledgment from the IISS.
003-323 IISS sending error detected by the controller. After commands were sent twice from
the controller, the controller could not receive acknowledgment from the IISS.
003-324 IISS sending error detected by the controller. After commands were sent twice from
the controller, the controller could not receive acknowledgment from the IISS.
003-325 IISS sending error detected by the controller. After commands were sent twice from
the controller, the controller could not receive acknowledgment from the IISS.
003-326 IISS sending error detected by the controller. After commands were sent twice from
the controller, the controller could not receive acknowledgment from the IISS.
003-327 IISS sending error detected by the controller. After commands were sent twice from
the controller, the controller could not receive acknowledgment from the IISS.
003-328 IISS sending error detected by the controller. After commands were sent twice from
the controller, the controller could not receive acknowledgment from the IISS.
003-329 IISS receiving error detected by the controller. The NAK that notifies of the occurrence
of a transmission failure is received.
003-330 IISS receiving error detected by the controller. The NAK that notifies of the occurrence
of a transmission failure is received.
003-331 IISS receiving error detected by the controller. The NAK that notifies of the occurrence
of a transmission failure is received.
003-332 IISS receiving error detected by the controller. The NAK that notifies of the occurrence
of a transmission failure is received.
003-333 IISS receiving error detected by the controller. The NAK that notifies of the occurrence
of a transmission failure is received.
003-334 IISS receiving error detected by the controller. The NAK that notifies of the occurrence
of a transmission failure is received.
003-335 IISS receiving error detected by the controller. The NAK that notifies of the occurrence
of a transmission failure is received.
003-336 IISS receiving error detected by the controller. The NAK that notifies of the occurrence
of a transmission failure is received.
003-337 There was no response to the power on command sent to the IISS after restoring from
power saver mode.
003-338 Incorrect argument error for sending.
003-339 Transmission establishing error for sending.
003-340 Synchronous send error.
003-341 Transmission error for sending.
003-342 Incorrect argument error for receiving.
003-343 Synchronous receive error.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. Perform the OF2 Special Boot Modes RAP.
