April 2017
2-494
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
092-911 to 092-914, 093-918, 093-335, 093-916, 093-
Launch Issue
Status Indicator RAPs
092-911 to 092-914, 093-918, 093-335, 093-916 Toner CRUM
Communication Error RAP
BSD-ON: BSD 9.4 Toner Cartridge Life Control
092-911 For information only, no service action necessary.
092-912 For information only, no service action necessary.
092-913 For information only, no service action necessary.
092-914 The system detected that the data written to the toner CRUM and the data read from
the toner CRUM do not match.
092-918 For information only, no service action necessary.
093-335 Toner CRUM authentication IC communication error.
093-916 Toner cartridge CRUM is not installed in the predetermined position.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
1. Switch off, then switch on the machine, GP 10.
2. Remove, then reinstall the toner cartridge.
3. Check the toner cartridge CRUM connector for damage and contamination. Use a dry
cloth to wipe the joining terminal between the toner cartridge CRUM PWB and the con
-
nector assembly.
4. Check the wiring between the drive PWB ( P/J411) and the toner CRUM connector
assembly ( P/J113) for an open circuit, short circuit or poor contact.
5. If the fault persists, install new components as necessary:
• Toner cartridge, PL 90.05 Item 1.
• Toner CRUM connector assembly, PL 90.10 Item 3.
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
093-400, 093-406 Toner Cartridge Near End of Life RAP
093-400 Toner cartridge is near end of life.
093-406 Toner cartridge is near end of life.
Procedure
Information only. No service action necessary. Advise the customer that the toner cartridge is
almost empty.
