April 2017
2-38
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
005-125, 005-145, 005-131, 005-132
Launch Issue
Status Indicator RAPs
005-125, 005-145 DADF Registration Sensor Off Jam RAP
BSD-ON: BSD 5.6 Document Scan, Invert and Exit Transportation
005-125 After the DADF pre registration sensor turned off at scan operation, the DADF regis-
tration sensor did not turn off within the specified time.
005-145 After the DADF pre registration sensor turned off at invert operation, the DADF regis-
tration sensor did not turn off within the specified time.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check for a foreign substance in the document path.
2. Check the surface of the registration roll, out roll and exit roll for foreign substances or
wear. Clean or install new components as necessary, PL 5.50.
3. Enter dC330, code 005-110. Check the DADF registration sensor, PL 5.70 Item 3.
4. Enter dC330, code 005-206. Check the DADF pre registration sensor, PL 5.70 Item 3.
5. Enter dC330, code 005-008. Check the DADF feed motor, PL 5.30 Item 3.
6. Check the drive gears, PL 5.35 for wear or damage. Install new components as neces-
sary.
7. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
005-131, 005-132 DADF Invert Sensor On Jam During
Inverting RAP
BSD-ON: BSD 5.6 Document Scan, Invert and Exit Transportation
005-131 After the DADF registration sensor turned on at invert operation, the DADF invert sen-
sor did not turn on within the specified time.
005-132 DADF invert sensor will not turn on after DADF registration sensor on in simplex.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check for a foreign substance in the document path.
2. Check the surface of the out roll for foreign substances or wear. Clean or install new com-
ponents as necessary, PL 5.50.
3. Enter dC330, code 005-211. Check the DADF invert sensor, PL 5.50 Item 8.
4. Enter dC330, code 005-110. Check the DADF registration sensor, PL 5.70 Item 3.
5. Enter dC330, code 005-008. Check the DADF feed motor, PL 5.30 Item 3.
6. Check the drive gears, PL 5.35 for wear or damage. Install new components as neces-
sary.
7. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
