Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
IQS 7
Launch Issue
Imaqe Quality
IQS 7 Registration
Documents
Test patterns: 82E2010 (A4), 82E2020 (8.5 X 11).
Print Registration Specifications
Refer to Table 1.
NOTE: For a description of the print/copy orientation definitions, refer to GP 31 Print/Copy Ori-
entation Definitions.
Registration Measurement
Perform dC126, make selections to print the test pattern on A3 or 11x17 inch paper.
Use the measurements Sa and Sb at each end of the inboard edge to measure the displace-
ment of the top of the image from the paper inboard edge, refer to IQ1 Figure 1.
Use the measurements La and Lb at each end of the lead edge to measure the displacement
of the side of the image from the paper lead edge.
NOTE: If a there is a difference between any pair of measurements, refer to IQS 5 Skew.
Corrective Action
Perform dC126 System Registration.
Copy Registration Specifications
Refer to Table 2.
Registration measurement
Make a copy of test pattern 82E2010 (A4) or 82E2020 (8.5x11).
Use the grids A and B on the copy, Figure 1, to measure the displacement of the lead edge
compared to the test pattern. Use the grid C to measure the top edge displacement. The dis
-
placement measured at A and B should be equal.
NOTE: Grid A and grid B of test patterns 82E2000, 82E2010, 82E2020 are small areas of par-
allel lines 1mm apart. These can be used to directly measure the registration displacement.
NOTE: If a there is a difference between measurements at A and B, refer to IQS 5 Skew.
Corrective Action
As necessary, perform ADJ 60.2 IIT Lead Edge Registration or ADJ 60.3 Side Edge Registra-
tion.
Table 1 Registration measurement
Parameter Measurement/Tolerance
Lead edge registration error on a simplex sheet 10 +/- 1.6 mm (0.39 +/- 0.063 inch)
Lead edge registration error on a duplex sheet 10 +/- 2 mm (0.39 +/- 0.079 inch)
Top edge registration error on a simplex sheet 10 +/- 2.1 mm (0.39 +/- 0.082 inch)
Top edge registration error on a duplex sheet 10 +/- 2.1 mm (0.39 +/- 0.082 inch)
Table 2 Registration measurement
Parameter Tolerance
Lead edge registration error on a simplex sheet +/- 1.6 mm (0.063 inch)
Lead edge registration error on a duplex sheet +/- 2 mm (0.079 inch)
Top edge registration error on a simplex sheet +/- 2.1 mm (0.082 inch)
Top edge registration error on a duplex sheet +/- 2.1 mm (0.082 inch)
