April 2017
2-464
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
062-345, 062-360, 062-389
Launch Issue
Status Indicator RAPs
062-345 IIT EEPROM Fail RAP
BSD-ON: BSD 6.3 Document Illumination and Image Input
062-345 Write failure to IEEPROM, or communication failure with EEPROM.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
1. Switch off, then switch on the machine, GP 10.
2. If the fault persists, install a new CCD Assembly, PL 60.10 Item 4.
062-360, 062-389 Carriage Position Fail RAP
BSD-ON: BSD 6.2 Carriage Control
062-360 Any of the faults that follow was detected:
• An error with the count value of the carriage position control.
• No IIT registration sensor input during carriage initialization.
• Abnormality in detected position of IIT registration sensor.
062-389 A Carriage overrun was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Remove the document glass. Manually move the full rate carriage to right and left.
The carriage moves smoothly, with no interference.
YN
Check the carriage operation for mechanical load, the carriage cable for winding failure,
the rail for contamination/foreign substances, and the full rate/half rate carriage for
improper position. Refer to ADJ 60.1. Install new components as necessary, PL 60.15.
Enter dC330 code 062-212. Manually move the carriage to actuate IIT registration sensor, PL
60.30 Item 7.
The display changes.
YN
Check the IIT registration sensor. Refer to GP 7 How to Check a Sensor.
Enter dC330 code 062-005 (scan) or 062-006 (return) to run the IIT scan motor, PL 60.30 Item
5.
The IIT scan motor runs and drives the carriage.
YN
Check the items that follow:
• The IIT scan motor. Refer to GP 6 How to Check a Motor.
• The timing belt, PL 60.30 Item 1.
Install new components as necessary.
The fault may be intermittent. If the fault persists, install new components as necessary:
• IIT registration sensor, PL 60.30 Item 7.
• IIT scan motor, PL 60.30 Item 5.
• ESS PWB, PL 3.10 Item 6.
To Next Page
