April 2017
2-72
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-291, 012-291A
Launch Issue
Status Indicator RAPs
012-291 Stapler Fail Entry RAP
012-291 Within a specified time after the staple motor started rotating in reverse direction, the
staple head home sensor was not detected turning on.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-291A Stapler Fail RAP.
• Office finisher LX installed, 012-291B Stapler Fail RAP.
012-291A Stapler Fail RAP
BSD-ON: BSD 12.5 Integrated Office Finisher Staple Control
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-291 Stapler Fail Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check that the staple assembly and cartridge are correctly installed, not broken and
include no foreign objects.
• Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330 012-046 and 012-047 alternately. The staple motor runs.
YN
Check the connections of P/J8705 and P/J8735. The connectors are good.
YN
Connect P/J8705 and P/J8735 securely.
Check for an open or short circuit between P/J8705 and P/J8735. The wiring is good.
YN
Repair the open wire or short circuit.
Enter dC330 012-046 and 012-047 alternately. Measure the voltages between finisher
PWB P/J8705 pins 3, 4, 5, 6 (+) and ground (-).
Each voltage changes.
YN
Check the wires and connectors for an intermittent open or short circuit. If the fault
persists, install a new finisher PWB, PL 12.14 Item 1.
Install a new staple assembly, PL 12.11 Item 2.
Enter again dC330 code 012-046 and 012-047 alternately. The display changes.
YN
Check the connections of P/J8701 and P/J8731. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8701 and P/J8731. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8701 pin 9 (+) and ground (-). The
voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
A B
To Next Page
