Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-213, 012-221B, 012-223B
Launch Issue
Status Indicator RAPs
Enter dC330 code 012-263. Manually rotate the encoder, PL 13.15 Item 19 to actuate the
stacker encoder sensor.
The display changes.
YN
Check the wiring between J8875 pin 2 and P/J8988 pin 23 for an open or short circuit, or
a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8988 pins 22 and 24 on the finisher PWB. The voltage
is approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between P/J8988 pin 23 on the finisher PWB and ground. Manually
rotate the encoder, PL 13.15 Item 19 to actuate the stacker encoder sensor.
The voltage
changes.
YN
Install a new stacker encoder sensor, PL 13.15 Item 32.
Install a new finisher PWB, PL 13.45 Item 2.
Enter dC330 code 012-262. Actuate the stacker no paper sensor, PL 13.15 Item 32. The dis-
play changes.
YN
Check the wiring between J8872 pin 2 and P/J8988 pin 14 for an open or short circuit, or
a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8988 pins 13 and 15 on the finisher PWB. The voltage
is approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between P/J8988 pin 14 on the finisher PWB and ground. Actuate
the stacker no paper sensor.
The voltage changes.
YN
Install a new stacker no paper sensor, PL 13.15 Item 32.
Install a new finisher PWB, PL 13.45 Item 2.
Install a new finisher PWB, PL 13.45 Item 2.
012-221B, 012-223B Front Tamper Home Sensor Fail RAP
BSD-ON: BSD 13.3 Office Finisher LX Interlock Switching
BSD-ON: BSD 13.9 Office Finisher LX Tamping and Offset (1 of 2)
BSD-ON: BSD 13.10 Office Finisher LX Tamping and Offset (2 of 2)
Procedure
NOTE: Ensure the correct RAP is performed, refer to the 012-221, 012-223 Front Tamper
Home Sensor Fail Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Manually operate the tamper mechanism. The tamper mechanism moves smoothly.
YN
Install a new components as necessary, PL 13.28.
Enter dC330 code 012-220 front tamper home sensor. Manually operate the tamper mecha-
nism to actuate the front tamper home sensor. The display changes.
YN
Check the wiring between J8881 pin 2 and J8984 pin 5 for an open or short circuit, or a
loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between J8984 pins 6 and 4 on the finisher PWB. The voltage is
approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between J8984 pin 5 on the finisher PWB and ground. Manually
operate the tamper mechanism to actuate the front tamper home sensor.
The voltage
changes.
YN
Install a new front tamper home sensor, PL 13.28 Item 8.
Install a new finisher PWB, PL 13.45 Item 2.
Enter dC330 012-020 and 012-023 alternately. The front tamper motor runs.
YN
Measure the voltage between J8984 pin 19 on the finisher PWB and ground. The volt-
age is approximately +24VDC.
YN
Measure the voltage between J8982 pin 4 on the finisher PWB and ground. The
voltage is approximately +24VDC.
A
A B
To Next Page
