Xerox VersaLink B7035 Service Manual

April 2017
6-51
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
General Procedures and Information
Launch Issue
Input Codes
Table 1 Input codes 005
Code Displayed Name Description General
005-102 Document Sensor Document sensor (Q05-102) High = document
present
005-110 Regi Sensor Registration sensor (Q05-110) High = no docu-
ment
005-206 CVT Pre Regi Sensor Pre-registration sensor (Q05-206) High = no docu-
ment
005-211 CVT Invert Sensor Invert sensor (Q05-211) High = no docu-
ment
005-212 CVT Feeder Cover
Interlock Switch
CVT feeder cover sensor (Q05-212) High = Cover
closed
005-213 CVT DADF Interlock
Switch
CVT DADF interlock switch (S05-
213)
High = DADF low-
ered
005-215 CVT #1 Tray APS Sen-
sor (CVT)
Tray APS sensor 1 (Q05-215) High/Low
005-216 CVT #2 Tray APS Sen-
sor (CVT)
Tray APS sensor 2 (Q05-216) High/Low
005-217 CVT #3 Tray APS Sen-
sor (CVT)
Tray APS sensor 3 (Q05-217) High/Low
005-218 CVT APS No. 1 Sensor APS sensor 1 (Q05-218) Low = document
present
005-219 CVT APS No. 2 Sensor APS sensor 2 (Q05-219) Low = document
present
005-220 CVT APS No. 3 Sensor APS sensor 3 (Q05-220) Low = document
present
005-221 CVT Tray Size SNR No.
1
Tray size sensor 1 (Q05-221) Low = document
present
005-222 CVT Tray Size SNR No.
2
Tray size sensor 2 (Q05-222) Low = document
present
005-224 Scan Start (CVT) Scan count signal. High = on
005-226 #2 Invert Sensor (PF1) Invert sensor 2 (Q05-226) Low = document
present
005-234 Home Position SNR Link home position sensor (Q05-
234) for nip release
High = nip closed
Table 2 Input Codes 012 - Integrated Office Finisher
Code Displayed Name Description General
012-111 IOT Exit Sensor IOT exit sensor (Q12-111) High/Low
012-140 Ent Sensor Entry sensor (Q12-140) High/Low
012-150 Compile Exit Sensor Compiler exit sensor (Q12-150) High/Low
012-220 Front Tamper Home
Sensor
Front tamper home sensor (Q12-
220)
High = home
012-221 Rear Tamper Home
Sensor
Rear tamper home sensor (Q12-
221)
High = home
012-242 Low Staple Sensor Low staples sensor (Q12-242) High = almost
empty
012-243 Self Priming Sensor Self priming sensor (Q12-243) High = ready
012-244 Staple Home Sensor Staple head home sensor (Q12-244) High = staple head
home
012-251 Set Clamp Home Sen-
sor
Set clamp home sensor (Q12-251) High = set clamp
home
012-252 Eject Home Sensor Ejector home sensor (Q12-252) High = Ejector
home
012-267 Stack Height Sensor Stack height sensor (Q12-267) High/Low
012-278 Stack Sensor1 Stack sensor 1 (Q12-278) High/Low
012-279 Stack Sensor2 Stack sensor 2 (Q12-279) High/Low
012-300 Top Cover Interlock Top cover interlock switch (S12-302) High/Low
012-302 Finisher Front Door SW Font door interlock switch (S12-302) High/Low
Table 3 Input Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General
012-100 Transport Entrance
Sensor
Transport entry sensor (Q12-100) High/Low
012-110 Reg. Clutch on Detect Registration clutch (CL12-110) On/off
012-111 IOT Exit Sensor IOT exit sensor (Q12-111) High/Low
012-150 Compile Exit Sensor Compiler exit sensor (Q12-150) High/Low
012-151 Compiler Tray No Paper
Sensor
Compiler tray no paper sensor (Q12-
151)
High/Low
012-190 H-Transport Entrance
Sensor
H-transport entrance sensor (Q12-
190)
High/Low
012-220 Front Tamper Home
Sensor
Front tamper home sensor (Q12-
220)
High = home
012-221 Rear Tamper Home
Sensor
Rear tamper home sensor (Q12-
221)
High = home
012-241 Stapler Move Position
Sensor
Stapler move position sensor (Q12-
241)
High/Low
012-242 Low Staple Sensor Low staples sensor (Q12-242) High = almost
empty
012-243 Self Priming Sensor Self priming sensor (Q12-243) High = ready
012-244 Staple Home Sensor Staple head home sensor (Q12-244) High = staple head
home
012-250 Eject Clamp Home Sen-
sor
Eject clamp home sensor (Q12-250) High/Low
012-251 Set Clamp Home Sen-
sor
Set clamp home sensor (Q12-251) High = set clamp
home
Table 2 Input Codes 012 - Integrated Office Finisher
Code Displayed Name Description General

Xerox VersaLink B7035 Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5.4 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	-
Input color depth	24 bit
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	129000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, TIFF, XPS
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, NFC, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Y
Linux operating systems supported	Fedora 24, openSUSE 13.2
Other operating systems supported	IBM AIX 7.2
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Pro x64, Windows 8 x64
Sustainability certificates	ENERGY STAR
Total input capacity	- sheets
Paper tray media types	Bond paper, Card stock, Envelopes, Heavy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	767.9 mm
Weight	- g
