Xerox VersaLink B7035 Service Manual

April 2017
6-54
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
Launch Issue
General Procedures and Information
Table 8 Output Codes 012 - Integrated Office Finisher
Code Displayed Name Description General
012-013 Sub Paddle Solenoid Energizes the sub paddle solenoid
(SOL12-013).
CAUTION
Do not run with 012-014. Running
these codes at the same time can
cause damage to the machine.
On/off. 660ms
timeout.
012-014 Sub Paddle Rotation Simultaneously runs the transport
motor (MOT12-095) and energizes
the paddle solenoid (SOL12-013) to
rotate the sub paddle once.
CAUTION
Do not run with 012-013, 012-095,
012-096 or 012-097. Running these
codes at the same time can cause
damage to the machine.
On/off. 660ms
timeout.
012-017 Set Clamp Motor Runs the set clamp motor (MOT12-
017).
CAUTION
Do not run with 012-061. Running
these codes at the same time can
cause damage to the machine.
On/off. 250 pulses.
012-020 Front Tamper Mot Low
Front
Runs the front tamper motor
(MOT12-020) at low speed to move
the front tamper forward.
On/off. 100 pulses.
012-021 Front Tamper Mot Mid-
dle Front
Runs the front tamper motor
(MOT12-020) at mid speed to move
the front tamper forward.
On/off. 100 pulses
012-022 Front Tamper Mot High
Front
Runs the front tamper motor
(MOT12-020) at high speed to move
the front tamper forward.
On/off. 100 pulses
012-023 Front Tamper Mot Low
Rear
Runs the front tamper motor
(MOT12-020) at low speed to move
the front tamper backward.
On/off. 100 pulses.
012-024 Front Tamper Mot Mid-
dle Rear
Runs the front tamper motor
(MOT12-020) at mid speed to move
the front tamper backward.
On/off. 100 pulses
012-025 Front Tamper Mot High
Rear
Runs the front tamper motor
(MOT12-020) at high speed to move
the front tamper backward.
On/off. 100 pulses
012-026 Rear Tamper Mot Low
Front
Runs the rear tamper motor
(MOT12-026) at low speed to move
the rear tamper forward.
On/off. 100 pulses.
012-027 Rear Tamper Mot Mid-
dle Front
Runs the rear tamper motor
(MOT12-026) at mid speed to move
the rear tamper forward.
On/off. 100 pulses
012-028 Rear Tamper Mot High
Front
Runs the rear tamper motor
(MOT12-026) at high speed to move
the rear tamper forward.
On/off. 100 pulses
012-029 Rear Tamper Mot Low
Rear
Runs the rear tamper motor
(MOT12-026) at low speed to move
the rear tamper backward.
On/off. 100 pulses.
012-030 Rear Tamper Mot Mid-
dle Rear
Runs the rear tamper motor
(MOT12-026) at mid speed to move
the rear tamper backward.
On/off. 100 pulses
012-031 Rear Tamper Mot High
Rear
Runs the rear tamper motor
(MOT12-026) at high speed to move
the rear tamper backward.
On/off. 100 pulses
012-046 Staple Motor FOR-
WARD
Runs the staple motor (MOT12-046)
forwards.
On/off.
012-047 Staple Motor REVERSE Runs the staple motor (MOT12-046)
in reverse.
On/off. 180ms
timeout.
012-054 Eject Motor Low FOR-
WARD
Runs the eject motor (MOT12-054)
at low speed to move the ejector out.
On/off. 2000 pulses
012-055 Eject Motor High FOR-
WARD
Runs the eject motor (MOT12-054)
at high speed to move the ejector
out.
On/off. 2000 pulses
012-056 Eject Motor Low
REVERSE
Runs the eject motor (MOT12-054)
at low speed to move the ejector
home.
On/off. 2000 pulses
012-057 Eject Motor High
REVERSE
Runs the eject motor (MOT12-054)
at high speed to move the ejector
home.
On/off. 2000 pulses
012-060 Stacker Motor UP Runs the stacker motor (MOT12-
060) to drive the stacker tray up.
On/Off. 80ms time-
out.
012-061 Stacker Motor DOWN Runs the stacker motor (MOT12-
060) to drive the stacker tray down.
On/Off. 80ms time-
out.
012-095 Transport Motor Low Runs the transport motor (MOT12-
095) forward at low speed (equal to
full IOT speed).
-
012-096 Transport Motor Hi Runs the transport motor (MOT12-
095) forward at high speed (trans
-
port speed in finisher).
-
012-097 Transport Motor Half
Speed
Runs the transport motor (MOT12-
095) forward at half speed (equal to
half IOT speed).
-
012-110 Registration Clutch ON Energizes the registration clutch
(CL12-110).
-
Table 8 Output Codes 012 - Integrated Office Finisher
Code Displayed Name Description General

Xerox VersaLink B7035 Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5.4 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	-
Input color depth	24 bit
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	129000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, TIFF, XPS
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, NFC, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Y
Linux operating systems supported	Fedora 24, openSUSE 13.2
Other operating systems supported	IBM AIX 7.2
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Pro x64, Windows 8 x64
Sustainability certificates	ENERGY STAR
Total input capacity	- sheets
Paper tray media types	Bond paper, Card stock, Envelopes, Heavy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	767.9 mm
Weight	- g
