April 2017
6-55
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
General Procedures and Information
Launch Issue
Table 9 Output Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General
012-013 Sub Paddle Solenoid Energizes the sub paddle solenoid
(SOL12-013).
On/off. 250 ms
012-018 Transport Motor
Reverse
Runs the transport motor (MOT12-
018) in reverse.
On/off.
012-020 Front Tamper Mot Low
Front
Runs the front tamper motor
(MOT12-020) at low speed to move
the front tamper forward.
On/off. 82 pulses
012-022 Front Tamper Mot High
Front
Runs the front tamper motor
(MOT12-020) at high speed to move
the front tamper forward.
On/off. 82 pulses
012-023 Front Tamper Mot Low
Rear
Runs the front tamper motor
(MOT12-020) at low speed to move
the front tamper backward.
On/off. 82 pulses
012-025 Front Tamper Mot High
Rear
Runs the front tamper motor
(MOT12-020) at high speed to move
the front tamper backward.
On/off. 82 pulses
012-026 Rear Tamper Motor Low
Front
Runs the rear tamper motor
(MOT12-026) at low speed to move
the rear tamper forward.
On/off. 82 pulses
012-028 Rear Tamper Motor
High Front
Runs the rear tamper motor
(MOT12-026) at high speed to move
the front tamper forward.
On/off. 82 pulses
012-029 Rear Tamper Motor Low
Rear
Runs the rear tamper motor
(MOT12-026) at low speed to move
the rear tamper backward.
On/off. 82 pulses
012-031 Rear Tamper Motor
High Rear
Runs the rear tamper motor
(MOT12-026) at high speed to move
the rear tamper backward.
On/off. 82 pulses
012-032 H-Transport Motor 1 Runs the horizontal transport motor
(MOT12-032) forward at highest
speed.
On/off.
012-033 H-Transport Motor 2 Runs the horizontal transport motor
(MOT12-032) forward at high speed.
On/off.
012-034 H-Transport Motor 3 Runs the horizontal transport motor
(MOT12-032) forward at mid speed.
On/off.
012-035 H-Transport Motor 4 Runs the horizontal transport motor
(MOT12-032) forward at low speed.
On/off.
012-036 Transport Motor 1 Runs the transport motor (MOT12-
036) forward at high speed.
On/off.
012-037 Transport Motor 2 Runs the transport motor (MOT12-
036) forward at mid speed.
On/off.
012-038 Transport Motor 3 Runs the transport motor (MOT12-
036) forward at low speed.
On/off.
012-039 H-Transport Motor
Reverse
Runs the horizontal transport motor
(MOT12-032) in reverse.
On/off.
012-040 Stapler Move Motor
Front Low
Runs the stapler move motor
(MOT12-040) to move the stapler
assembly to the front at low speed.
On/off.
012-042 Stapler Move Motor
Front High
Runs the stapler move motor
(MOT12-040) to move the stapler
assembly to the front at high speed.
On/off.
012-043 Stapler Move Motor
Rear Low
Runs the stapler move motor
(MOT12-040) to move the stapler
assembly to the rear at low speed.
On/off.
012-045 Stapler Move Motor
Rear High
Runs the stapler move motor
(MOT12-040) to move the stapler
assembly to the rear at high speed.
On/off.
012-046 Staple Motor Forward Runs the stapler motor (MOT12-
046) forwards.
On/off.
012-047 Staple Motor Reverse Runs the stapler motor (MOT12-
046) in reverse.
On/off. 200ms
timeout.
012-050 Set Clamp Clutch Energizes the set clamp clutch
(CL12-050).
On/off. 583 pulses.
012-052 Eject Clamp Up Runs the eject motor (MOT12-054)
in reverse at high speed to raise the
eject clamp roll.
On/off. 200ms
timeout.
012-053 Eject Clamp Down Runs the eject motor (MOT12-054)
in reverse at high speed to lower the
eject clamp roll.
On/off. 46 pulses
after home.
012-054 Eject Motor Forward
Low
Runs the eject motor (12-054) for-
ward at low speed.
On/off. 1136
pulses.
012-055 Eject Motor Forward
High
Runs the eject motor (12-054) for-
ward at high speed.
On/off. 1136
pulses.
012-060 Stacker Motor Up Runs the stacker motor (MOT12-
060) to drive the stacker tray up.
On/Off. 500ms
timeout.
012-061 Stacker Motor Down Runs the stacker motor (MOT12-
060) to drive the stacker tray down.
On/Off. 500ms
timeout.
012-074 Punch Motor Move
Home
Runs the punch motor (MOT12-074)
to drive the punch home.
On/off.
012-077 Punch (2 hole) Runs the punch motor (MOT12-074)
to drive 2 hole punch movement.
On/off.
012-078 Punch (3 hole) Runs the punch motor (MOT12-074)
to drive 3 hole punch movement.
On/off.
012-079 Punch (4 hole) Runs the punch motor (MOT12-074)
to drive 4 hole punch movement.
On/off.
013-022 Knife Motor Forward Runs the knife motor (MOT13-022)
forward.
On/off.
013-023 Knife Motor Reverse Runs the knife motor (MOT13-022)
in reverse.
On/off.
Table 9 Output Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General
