April 2017
2-105
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-210, 506, 777, 780, 798, 016-417
Status Indicator RAPs
Launch Issue
016-210, 506, 777, 780, 798 HDD Error RAP
BSD-ON: BSD 3.9 ESS
016-210 One of the SW option functions cannot be executed due to a HDD error or HDD not
installed.
016-506 The log image storage area on the disk is full, a job cannot be continued.
016-777 An error other than disk full was detected when opening/reading/writing file for com-
pression conversion/image processing operation.
016-780 An error other than HDD full was detected when opening/writing file for operation.
016-798 A HDD unavailable error was returned when the decomposer called the S-image
library.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Check the wiring between the ESS PWB, PL 3.10 Item 6 and the hard disk.
3. Initialise the hard disk. Refer to dC355 Image Disk Diagnostics.
4. Initialize the Sys - System NVM, refer to dC301.
5. Install a new hard disk, PL 3.10 Item 2.
016-417 Invalid Network Settings RAP
016-417 An invalid or improper network setting has prevented communication.
Procedure
Ensure all network settings are correct.
To Next Page
