Xerox VersaLink B7035 Service Manual

April 2017
3-6
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
IQ2
Launch Issue
Imaqe Quality
Regular toner contamination in the pro-
cess direction on side 2.
Xerographics There is a regular pitch toner contamination in the process direction on side 2. Perform the IQ16 Regular Toner
Contamination in the Process
Direction (Side 2) RAP.
Residual image (ghosting) Xerographics Ghost images appear on the paper. Parts of the previous page or current page may appear as ghost
images on the paper.
Perform the IQ3 Residual Image
(Ghosting) RAP.
Skew Xerographics Printed images are not parallel to the edges of the paper. Perform the IQ8 IOT Skew RAP.
Smear Transfer Black lines or blank areas running along the paper across the process direction. Perform the IQ17 Smear RAP.
Toner droplet contamination Xerographics Toner spills on the paper and smears in a long, narrow shape. Perform the IQ5 Toner Smears
RAP.
Toner splattering Xerographics There are many uneven black spots on parts of paper. Perform the IQ6 Toner Contami-
nation RAP.
Toner streak Xerographics A long thin line in the process direction. The length can range from 2mm (0.08 inch) to over 10cm (4
inches). This occurs in solids or halftones, it does not occur in the background.
Perform the IQ24 Toner Streak
RAP.
Unfused image Fusing Printed images are not correctly fused onto the paper. When rubbed, the image comes off easily. Perform the IQ21 Unfused Copy/
Toner Offset RAP.
White spots Transfer Toner spots and blank areas are spread irregularly over the whole page. Perform the IQ19 White Spots
RAP.
Table 1 IQ defects
Image Quality Defect Subsystem Symptom Action

Xerox VersaLink B7035 Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5.4 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	-
Input color depth	24 bit
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	129000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, TIFF, XPS
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, NFC, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Y
Linux operating systems supported	Fedora 24, openSUSE 13.2
Other operating systems supported	IBM AIX 7.2
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Pro x64, Windows 8 x64
Sustainability certificates	ENERGY STAR
Total input capacity	- sheets
Paper tray media types	Bond paper, Card stock, Envelopes, Heavy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	767.9 mm
Weight	- g
