Electrical component and wire harness routing
5-4
Front
CC
D
3
D
2
1
A
D-D
4
5
4
6
7
B
7
C-C
1. Fuse box
2. Engine ECM
3. Hour meter (tiller handle model)
4. TPS lead
5. Pulser coil lead
6. Fuse box lead
7. Hour meter lead (tiller handle model)
A. Insert the ECM couplers until they are
conn
ected.
B. Tiller handle model
