2 Installation and Commissioning, IRC5
2.9.2. Installation of external operator's panel, IRC5
1093HAC021313-001 Revision: K
© Copyright 2004-2008 ABB. All rights reserved.
7. Connect the ethernet connector A32.A8 to
the computer unit.
DSQC623:
xx0400000960
• A: Connector X8
DSQC639:
xx0600002897
• A: FlexPendant port
Action Info/Illustration
Slot 1 Slot 2 Slot 3
Slot 4
Slot 5
Continued
Continues on next page
