Accutome B-Scan Plus User Guide
Exam Information Displayed above Image
Above the Exam Screen’s Imaging area, in the top right
or left corner there is an area that displays some or all of
the following fields:
Probe Frequency (Prob Freq)
Maximum Probe Signal Depth (Max. Depth)
Medical Record Number (MRN)
Exam Creation Time (Date)
Facility - Facility display can be turned on or off
in B-Scan Plus Setup, Options tab
Physician - Physician display can be turned on
or off in B-Scan Plus Setup, Options tab
Operator - Operator display can be turned on
or off in B-Scan Plus Setup, Options tab
Current View in Image Sequence Protocol
The information fields displayed and the position of the
information
on the screen is determined by the Options
settings in Setup.
Current View
The Current View area displays the position of the
currently active step in the imaging sequence. The
position is displayed in both a textual and graphical
format. You can also edit the current view in this area.
There is also a "View" that allows you to view the image
frames for the previous sequence steps.
All Views
The All Views area displays all views in all steps of the
current imaging sequence.
