Accutome B-Scan Plus User Guide
Add View
The Add View function allows you to add new scan views
to the scanning sequence. To add a new view to the
current scanning sequence:
1. In
the All Views area select "Add View"
2. Label the new scan view.
3. In
the Current View area select OD or OS for the
new step.
4. The newly added scan will be active and display as
OD.Scan or OS.Scan.
5. Adju
st the new scan settings. Select the probe ori-
entation for the step: Axial, Longitudinal (Long) or
Transverse (Trans).
6. Sele
ct the view position indicator in the Current
View area and drag the indicator tip to the desired
position.
Edit Current View
When you select "Edit" in the Current View area the
B-Scan Plus allows changes to the currently active scan
view la
bel. Edit the label for the view. Make the
adjustments to the probe orientation or positions by
dragging the position indicator. The changes will be
reflected in the new name of the step. For example, if
you changed the probing orientation for OD.12AX to
Transverse, the new scan name is "OD.12T"
Probe Orientation
There are three probe orientations:
Axial
Long (Longitudinal)
Trans (Transverse)
Axial
Axial is the center of the cornea and is used to denote a
scan with the probe perpendicular to the cornea.
