Accutome B-Scan Plus - Depth; Figure 52 Selecting Probe Depth

70
Accutome B-Scan Plus User Guide
Depth
The depth field allows you to change the depth of the
probe signal. The depth options are dependent upon the
frequency selected:
 12 MHz - depths are 30 mm and 60 mm
 15 MHz mm - depths are 50 mm and 100 mm
The default probe settings are 12 MHz at 60 mm. To
chan
ge the depth select the appropriate value from the
drop down list located at the right of the depth field as
shown in Figure 52 below.
Figure 52 Selecting Probe Depth
