Accutome B-Scan Plus User Guide
Exam Information Displayed above Image
Above the Exam Screen’s Imaging area is an area that
displays some or all of the following fields:
Probe Frequency (Prob Freq)
Maximum Probe Signal Depth (Max. Depth)
Medical Record Number (MRN)
Exam Creation Time (Date)
Facility - Facility display can be turned on or off
in B-Scan Plus Setup, Options tab
Physician - Physician display can be turned on
or off in B-Scan Plus Setup, Options tab
Operator - Operator display can be turned on
or off in B-Scan Plus Setup, Options tab
Current View of stored scanned film loops
The default position for exam info
rmation fields is at the
top left of the screen. The information fields that are
displayed and the position on the screen where the fields
are displayed can be changed in the setup mode
Current View
The Current View area displays the position of the
currently active scan in the scanning sequence. The
position is displayed in both a textual and graphical
format. You can also edit the current view in this area.
Current View Orbital Locators
When you are examining a captured image the Current
View area will display, as you select, on the graphical
representation of the image the following orbits:
CB - Ciliary Body
O - Ora Serrata
EA - Equator Anterior
E - Equator
EP - Equator Posterior
PE - Posterior Equator
P - Posterior Pole
