Accutome B-Scan Plus - Archive to CD or DVD; Selecting Patient Exams; Figure 151 Selecting the First Exam; Selecting Individual Exams

193
Archive and Restore Archive to CD or DVD
Archive to CD
or DVD
The process to archive patient exams is extremely
simply; insert a disc in the CD/DVD drive, select the
exams and click burn. The steps to archive patient
exams to a CD/DVD are:
1. Insert a CD or DVD into the computer drive.
2. Select the patient exams you would like to archive.
3. Sele
ct "Burn Disc" on the CD/DVD Recordable
Media tab.
Selecting Patient Exams
When you launch the Archive function the B-Scan Plus
displays all exams found on the system at the left side of
the screen. You will select the exams to archive from
this list. You can select the exams one at a time or select
all exams at once.
Selecting Individual Exams
To select exams one at a time:
1. Cli
ck in the checkbox beside the exam name as
shown in Figure 151 below.
Figure 151 Selecting the First Exam
