If required, tap to undo the deletion.

After adjusting the clearance on the patient’s tooth, tap to return to Scan mode and rescan the deleted

area, which is marked in red.

Figure 161: Deleted area marked in red

Tap the Occlusal Clearance tool to confirm that the prepped tooth was sufficiently reduced.

10.7 Working with the Occlusal Clearance tool

The Occlusal Clearance tool enables you to view the contact and distance between the opposing teeth, for

example, to ensure that the prepped tooth has sufficient reduction for the material chosen in the Rx.

The Occlusal Clearance tool can be accessed while in View mode and from the Viewer.

Note: The Occlusal Clearance tool is displayed only after you have scanned the upper and lower jaws, and the

bite.
