2.4 Assembling the iTero Element 5D Plus and 5D Plus Lite scanner – mobile configuration
The scanner packaging is designed in a way that provides a simple and easy assembly process.
Follow the instructions below to assemble the scanner.
Contact iTero Support for additional help.
A Full HD touch-screen
computing unit
B Carrying handle/stand
C Cradle
D Wand
E Power supply
F Webcam (in the box)
G Power switch
This section describes how to:
l
Assemble the scanner, described in Initial assembly
l
Move the scanner within the clinic, described in Moving the scanner within the clinic
l
Pack the scanner in the trolley before transporting it described in Using the trolley for transportation
l
Protect the trolley with the optional protective cover, described in Optional protective cover
l
Mount the scanner on a VESA mount, described in VESA mounting
iTero Element 5D and iTero Element 5D Plus imaging systems User manual
