Figure 45: Home screen with notification about Windows security updates

A Windows progress bar is displayed during the installation. Once the updates have been installed, the

scanner restarts and the Login page is displayed.

4.2 Logging out of the scanner

In order to protect the patient information, you should log out of the scanner when it is not in use. Your password

will not be remembered by the system.

By default, you will be logged out after a predefined period of inactivity, which can be defined in the Login settings,

described in Defining the login settings.

To log out of the scanner:

Tap to return to the home screen.

Tap to log out of the system.

The Login window is displayed, ready for the next user to log in to the system.
