To create the die separation manually:

In the View window, tap the Die Separation tool .

The tool expands to show the following options:

Figure 172: Die Separation tool options

Tap and mark the whole segment with your finger.

The scan is displayed in low resolution.

Figure 173: Scan is displayed in low resolution
