4 Working with the scanner

4.1 Logging in to the scanner

When the scanner is powered on, the Login window is displayed.

Figure 37: Login window

Make sure you have your MyAligntech account information ready when logging in to the iTero scanner. You need

your name, account email, and password. Fill in all the necessary fields and then tap the Login button.

Notes:

In order to ensure that all Windows security patches are up-to-date, a notification is displayed at the bottom of

the Login window and the home screen as soon as security updates are available to be installed. For more

information on installing security updates, see Installing Windows security updates.

iTero Element 5D and iTero Element 5D Plus imaging systems User manual
