Align Technology iTero Element 5D - Touch-Screen Gestures

To Next Page

To Previous Page

In this view, the button changes to two additional buttons:

Tap for remote assistance from Customer Support. Customer Support is available

from every Help overlay.

Note: Please call Customer Support before trying to connect remotely.

Tap to access the relevant e-manual.

Tap anywhere to close the Help screen and return to the relevant screen.

4.5.2 Touch-screen gestures

The iTero software supports touch-screen (also known as multi-touch) gestures. These gestures are predefined

motions used to interact with multi-touch devices.

Examples of common touch-screen gestures:

iTero Element 5D and iTero Element 5D Plus imaging systems User manual
