Align Technology iTero Element 5D - iTero Element 5 D Wheel-Stand Specifications

D.1 iTero Element 5D wheel-stand configuration system specifications
Monitor 21.5” Full HD (1920x1080) touch screen
Wand
l
The wand emits red laser light (680nm Class 1), as well as white LED
emissions and 850nm LED emissions.
l
Wand operating power: 15VDC
Wireless LAN A LAN card provides local network communications with wireless
connectivity
l
2.4GHz, 5GHZ
l
802.11ac
Security See the product security whitepaper in iTero Element product security
whitepaper.
Operating Power 100-240 VAC- 50/60 Hz- 200 VA (max)
Operating Temperature 18°C to 26°C / 64.4°F to 78.8°F
Storage/Transportation
Temperature
-5°C to 50°C / 23°F to 122°F
Operating Pressure and
Altitude
Pressure: 520 mmHg to 771 mmHg (-69 kPa to -103 kPa)
Altitude: -400 feet to 10,000 feet
Storage/Transportation
Pressure and Altitude
Pressure: 430 mmHg to 760 mmHg (~57 kPa to ~101 kPa)
Altitude: 0 feet to 15,000 feet
Relative Humidity Operating: 40% to 70%
Storage: 30% to 90%
Dimensions iTero Full HD touch-screen
computing unit:
l
Height: 356 mm (~14 in)
l
Width: 552 mm (~21.7 in)
l
Depth: 65 mm (~2.5 in
Wand:
l
Length: 346 mm (13.3 in)
l
Width: 50 mm (~2.0 in)
l
Depth: 68 mm (~2.7 in)
Wheel stand:
l
Height: 1280 mm (~50 in)
l
Width: 645 mm (~25 in)
l
Depth: 625 mm (~24.5 in)
Net Weight Monitor: 8.3 kg (~18.3 lbs.)
Wand: 0.47 kg (~1.0 lbs.) without the cable
Wheel stand: ~13.6 kg (~30 lbs.)
iTero Element 5D and iTero Element 5D Plus imaging systems User manual
206 © 2022 Align Technology, Inc. All rights reserved.
