Selecting notationSelecting notation
Open the middle drop-down menu in the top row of buttons to select which
results you want to display on the screen.
OTNOTN SDHSDH, SONETSONET E1E1, E3E3, E4E4, DS1/J1DS1/J1, DS3DS3
Alarms/Errors
Performance
Alarms/Errors
Quality
Performance
TCM
Alarms/Errors
Performance
OTN options appear if the SDH/SONET signal is carried by OTN.
Touch a specific cell in a result table to zoom in on the corresponding result
item. The CountCount and RatioRatio fields are displayed on a ZoomZoom tab page. A Time vs.Time vs.
StatisticsStatistics tab page is also available. Touch the BackBack button to return to the
statistics screen.
Selecting how results are displayedSelecting how results are displayed
Select the required notation for the results from the notation drop-down menu.
UnformattedUnformatted - e.g. 71892
SI prefixSI prefix - e.g. 71.892 k (k means "kilo")
EngineeringEngineering - e.g. 71.892E3
ScientificScientific - e.g. 7.1892E4
ResultsResults
Results are displayed according to your choice. OTN appears when 'BERT on
OTN' is running.
OTN Alarms/Errors Refer to Results in "OTN Application"
OTN Performance Refer to Results in "OTN Application"
SDH Alarms/Errors Alarms
Errors
SDH Quality
Frequency *
1
MUX
AU VC-4/3
TU VC-3
