When copied MAC address by
setting with DecrementDecrement
When copied IPv6 address by setting with
IncrementIncrement
00-00-00-00-00-04 0000:0000:0000:0000:0000:0000:FFFF:FFFC
00-00-00-00-00-03 0000:0000:0000:0000:0000:0000:FFFF:FFFD
00-00-00-00-00-02 0000:0000:0000:0000:0000:0000:FFFF:FFFE
00-00-00-00-00-01 0000:0000:0000:0000:0000:0000:FFFF:FFFF
00-00-00-00-00-00 0000:0000:0000:0000:0000:0000:FFFF:0000
00-00-00-00-00-FF 0000:0000:0000:0000:0000:0000:FFFF:0001
00-00-00-00-00-FE 0000:0000:0000:0000:0000:0000:FFFF:0002
00-00-00-00-00-FD 0000:0000:0000:0000:0000:0000:FFFF:0003
: :
Stream Setup (detailed mode dialog box)Stream Setup (detailed mode dialog box)
This dialog box provides you with the advanced options for configuring the
Ethernet frame content for a specific stream. Use the buttons in the following
figure to select the stream.
The buttons on the left-hand side of the dialog box allow you to select the
relevant layers. The current selection is shown at the top of the Frame ContentFrame Content
area. Touching one of the layer buttons in the Frame ContentFrame Content area will display
the setup parameters for that layer.
The layer buttons are arranged in order from bottom to top and from left to
right. The TCP/UDP protocols are the uppermost layer and Ethernet the
lowermost as depicted below compared to the OSI model.
