Y.1731 protocol setupY.1731 protocol setup
MEP IDMEP ID
Allows you to specify the Local Maintenance Point ID, which will identify the
unit in the MA.
DomainDomain
Allows you to identify the network or part of the network for which faults in
connectivity are managed.
MD LevelMD Level
Use the drop-down menu to specify the level at which the MEP exists.
AssociationAssociation
Allows you to specify the Main Association Identifier.
CCM tab pageCCM tab page
The CCMCCM tab page contains the following parameter:
CCM intervalCCM interval
Use the drop-down menu to specify the frequency at which CCMs are
transmitted and expected to be received.
LBM tab pageLBM tab page
The LBMLBM tab page contains the following parameters:
Optional TLVOptional TLV
Use the drop-down menu to select a TLV type, if relevant. The possible types
are: Data TLVData TLV and Test TLVTest TLV. If you select one of the TLV types, fields for
specifying the length and value will appear.
LengthLength
Only available if a Data or Test TLV type has been selected. Allows you to
specify the length of the TLV.
ValueValue
Only available if a Data or Test TLV type has been selected. Allows you to
specify the value of the TLV. Note that for the Data TLV type, this field is an
entry field where you open an editor and type the value; for the Test TLV type,
it is a drop-down menu.
LTM tab pageLTM tab page
The LTMLTM tab page contains the following parameters:
TTLTTL
Allows you to specify a TTL value. Used to indicate whether or not an LTM
should be terminated by the receiver.
Trans IDTrans ID
Allows you to specify the transaction number for the LTM.
Selecting the Y.1731Y.1731 protocol will display the screen shown below.
