Line Load (Mbps)Line Load (Mbps)
DurationDuration
Frame size is protocol headers and payload combined. Frame size does not include
preamble and interframe gap.
The different test line loads used in the test are specified as a Minimum (MinMin)
and Maximum (MaxMax) - varied in intervals of the value specified in the StepStep
field. The test always starts at Maximum line load and decreases until the line
load is less than Minimum. The results can be presented in either MbpsMbps or as
PercentPercent.
Valid range of
Min
,
Max
,
Step
depends on the unit and Ethernet interface.
Percent
0.0008 to 100.0000 %.
Mbps
10M interface: 0.00008 to 10.000 Mbps *
1
100M interface: 0.0008 to 100.00 Mbps *
1
1G interface: 0.008 to 1000.00 Mbps *
1
10G interface: 0.08 to 10000.00 Mbps *
2
*1: Setting is only available with the Ethernet 10/100/1000 interface.
*2: Setting is only available when the Ethernet 10 Gig option is installed.
Stop on no frame loss at maximum utilizationStop on no frame loss at maximum utilization
The test will continue to test the next frame size if the current test step at a
specific line load and frame size does not have any frames lost.
Auto searchAuto search
Allows you to let the test automatically find the maximum line load that gives
zero frame loss, using a specified resolution. Auto Search can run in one of the
two following modes:
SmartSmart that assumes that there is a higher probability of frame loss occurring
closer to Max, and therefore makes a skewed binary search searching the
higher line loads first.
BinaryBinary that will perform a binary search of the specified line load interval
from Max to Min.
The ResolutionResolution field lets you specify the precision of the auto search. A higher
precision extends the duration of the test. Available resolutions are: 0.10.1, 1.01.0
and 10.010.0 %.
The check boxes are enabled except when selecting 'End to End network test' on Control
screen.
StepStep
Specify the approximate duration in time of each step of the test. It can be set
to a number of seconds (minimum 3 seconds).
RepeatsRepeats
Specify the number of times the complete test will repeat. Valid range: 00 to
10001000.
66..99..22..33 Frame LossFrame Loss
