Site Names (Short,Site Names (Short,
Long)Long)
End to End Test SetupEnd to End Test Setup
Frames from Service 1 on the local side must reach Service 1 on the remote side and
vice versa. This applies to all services.
When the End to End test is started, a popup will appear on the remote side,
telling that the unit is being remotely controlled and allowing the user to break
the connection, if required. The popup will disappear when the test is
completed or stopped on the local side.
When the End to End test is completed, the test results are transferred from the
remote side to the local side.
Round-Trip TestRound-Trip Test
This test mode is used when testing network by reflecting traffic back to the
instrument. This requires a device to reflect the traffic back, for instance a
second Network Master.
A remote side Network Master in Reflector mode must have Swap IP address and Swap
Ports on UDP and TCP frames enabled.
Touch the fields to set the Site Names :
LocalLocal: The site name for 'local' Network Master side.
RemoteRemote: The site name for 'remote' Network Master side.
This setup is enabled when One-Way TestOne-Way Test is selected.
DirectionDirection
Use the check boxes to specify which directions to test. Ethernet frames are
sent from left side site name to right side site name. Ethernet frames received at
right site will be measured.
LineLine
Use the drop-down menu to select how the service attributes for the directions
are set up.
SymmetricalSymmetrical: The same service attributes are used for both directions.
AsymmetricalAsymmetrical: Service attributes are set up for each direction.
Test Sync. ModeTest Sync. Mode
Use the drop-down menu to select the method for synchronization of the two
instruments performing the test. Synchronization is required for correct
measurement of FTD and FDV in End to End Test mode.
Select GPSGPS if external GPS receivers are available at both the local and the
remote site. This gives the most accurate measurements.
Select Pre-test sync.Pre-test sync. if GPS is not available for both instruments. In this mode,
synchronization is obtained using proprietary protocol prior to the first step of
the Service Configuration Test.
External GPS sensor is available from Anritsu (part no. G0325A or MU100090A).
Use local SRC as DST on remote sideUse local SRC as DST on remote side
