Enable/DisableEnable/Disable
serviceservice
If the End to End test setup on the 'Control' screen has been set to asymmetrical service
attributes setups, two Services buttons are displayed instead of one: Services L->R
button and Services R->L button.
This screen allows you to configure up to eight services being tested in the
current Service Activation Test. For each service, you can:
Enable/Disable the service
Set up the profile
Set up the bandwidth
Set up the service acceptance criteria (thresholds)
Set up the color aware
Set up the frame size configuration
Select the services that are to be tested. Up to 8 services can be specified,
either by enabling already defined services or by defining new ones. Use the
stream slide-out to select the relevant services. The stream slide-out is
displayed via the tab in the top left-hand corner of the setup area.
Use the EnabledEnabled check box to enable/disable the service specified in the
ServiceService field.
