Green The item and all its sub items are passing or have passed the Service
Acceptance Criteria.
Yellow The GPS synchronization has been lost for a following period or more.
G0325A: 10 seconds
MU1000090A: 1 hour
FTD and FDV results could be compromised if the duration of
continuous GPS synchronization loss has been longer the this time FTD
and FDV results are compromised.
Red The items and one or more of its sub items have failed the Service
Acceptance Criteria.
Gray Results for the item are pending.
Blue The measurement is running.
GPS status LampGPS status Lamp
When Test Sync. Mode is set to GPSGPS on Control screen, status
for the GPS time synchronization is displayed at the top of the
screen with colored Lamps - one Lamp for the local side and
one for the remote side.
Green GPS synchronization is OK.
Yellow GPS synchronization has been lost for 10 seconds (1 hour for
MU1000090A) or more. FTD and FDV results could be compromised.
66..1111..33..22 Configuration TestConfiguration Test
Touching the Configuration TestConfiguration Test button in the navigation area will display the
screen shown below.
This screen presents the detailed Configuration Test results for a specific
service. Use the drop-down menu at the top of the screen to select which
service to view.
