STM16(Async)STM16(Async): Synchronous Transport Module-16 (2488.32 Mbit/s)
STM16(Sync)STM16(Sync): Synchronous Transport Module-16 (2488.32 Mbit/s)
STM4STM4: Synchronous Transport Module-4 (622.08 Mbit/s)
STM1STM1: Synchronous Transport Module-1 (155.52 Mbit/s)
STS192(Async)STS192(Async): Synchronous Transport Signal-192 (9953.28 Mbit/s)
STS192(Sync)STS192(Sync): Synchronous Transport Signal-192 (9953.28 Mbit/s)
STS48(Async)STS48(Async): Synchronous Transport Signal-48 (2488.32 Mbit/s)
STS48(Sync)STS48(Sync): Synchronous Transport Signal-48 (2488.32 Mbit/s)
STS12STS12: Synchronous Transport Signal-12 (622.08 Mbit/s)
STS3STS3: Synchronous Transport Signal-3 (155.52 Mbit/s)
Trans.(PRBS)Trans.(PRBS): PRBS without SDH/SONET header (Same setting as PRBS in
OTN application)
Trans.(Null)Trans.(Null): Null without SDH/SONET header (Same setting as NULL in OTN
application)
For the Fiber Channel +OTN application
FC100FC100: Fibre Channel 100 Mbyte/s (1.0625 Gbit/s)
FC200FC200: Fibre Channel 200 Mbyte/s (2.125 Gbit/s)
FC400FC400: Fibre Channel 400 Mbyte/s (4.25 Gbit/s)
FC800FC800: Fibre Channel 800 Mbyte/s (8.5 Gbit/s)
FC1200FC1200: Fibre Channel 1200 Mbyte/s (10.51875 Gbit/s)
For the CPRI +OTN application
614.4 M(CPRI)614.4 M(CPRI): CPRI Option 1 (614.4 Mbit/s)
1228.8 M(CPRI)1228.8 M(CPRI): CPRI Option 2 (1228.8 Mbit/s)
2457.6 M(CPRI)2457.6 M(CPRI): CPRI Option 3 (2457.6 Mbit/s)
3072.0 M(CPRI)3072.0 M(CPRI): CPRI Option 4 (3072.0 Mbit/s)
4915.2 M(CPRI)4915.2 M(CPRI): CPRI Option 5 (4915.2 Mbit/s)
6144.0 M(CPRI)6144.0 M(CPRI): CPRI Option 6 (6144.0 Mbit/s)
9830.4 M(CPRI)9830.4 M(CPRI): CPRI Option 7 (9830.4 Mbit/s)
10137.6 M(CPRI)10137.6 M(CPRI): CPRI Option 8 (10137.6 Mbit/s)
Multiplexing 1Multiplexing 1
Applicable when there are two or more levels of multiplexing. Defines into
which higher order the second level ODU is mapped.
NoneNone
ODTU4.1ODTU4.1 : One 1.25G Tributary Slot (TS)
ODTU4.2ODTU4.2 : Two 1.25G Tributary Slots (TS)
ODTU4.8(ODU2)ODTU4.8(ODU2) : Eight 1.25G Tributary Slots (TS)
ODTU4.8(Ext. OPU2)ODTU4.8(Ext. OPU2) : Eight 1.25G Tributary Slots (TS)
ODTU4.8(ODU2e)ODTU4.8(ODU2e) : Eight 1.25G Tributary Slots (TS)
ODTU3.1ODTU3.1 : One 1.25G Tributary Slot (TS)
ODTU23 (PT=20)ODTU23 (PT=20) : Supports 2.5G Tributary Slot (TS).
ODTU23 (PT=20)(Ext. OPU2)ODTU23 (PT=20)(Ext. OPU2) : Supports 2.5G Tributary Slot (TS).
ODTU23 (PT=21)ODTU23 (PT=21) : Supports 1.25G Tributary Slot (TS).
ODTU23 (PT=21)(Ext. OPU2)ODTU23 (PT=21)(Ext. OPU2) : Supports 1.25G Tributary Slot (TS).
ODTU13 (PT=20)ODTU13 (PT=20) : Supports 2.5G Tributary Slot (TS).
ODTU13 (PT=21)ODTU13 (PT=21) : Supports 1.25G Tributary Slot (TS).
ODTU2e3e1ODTU2e3e1 : Supports 1.25G Tributary Slot (TS).
ODTU3e2.8ODTU3e2.8 : Supports 2.5G Tributary Slot (TS).
ODTU2.1ODTU2.1 : One 1.25G Tributary Slot (TS)
ODU2(Ext. OPU2)ODU2(Ext. OPU2) : One 1.25G Tributary Slot (TS)
OTN Setup and StatusOTN Setup and Status
