If low order ODU is mapped, Payload OffsetPayload Offset field appears. Touch the field to set
the payload offset. The calculated C
m
and C
nD
will be displayed when using
GMP.
77..11..44..44 OTN justificationOTN justification
OTN justification is available when ODTUjk is selected to the Multiplexing 1 in
Mapping dialog box.
1. Select LevelLevel to insert the justification.
2. Touch the Burst lengthBurst length field, the dialog box will appear.
3. Select the MovementMovement of the justification.
Positive (+1): positive justification
Positive (+2): double positive justification
Positive (+3): triple positive justification
Negative (-1): negative justification
Negative (-2): double negative justification
4. Touch the Apply MoveApply Move button to insert the justification bytes.
