Selecting the intervalSelecting the interval
timetime
Select the pattern. You can edit bit pattern when the pattern is User[32] bit or
User[2048] bit.
Pattern Error InsertionPattern Error Insertion
Select the check box to enable the pattern error insertion.
Select Insertion Mode to SingleSingle or RateRate. When SingleSingle is selecting, touch
Alarm/Error Insert icon in the Application Toolbar.
77..33..33..22 Event LogEvent Log
Touching the Event LogEvent Log button in the navigation area displays the screen
providing the event log data. Refer to Event Log of SDH/SONET/PDH/DSn
BERT application.
77..33..33..33 StatisticsStatistics
Touching the StatisticsStatistics button in the navigation area displays the screen shown
below.
This screen presents a detailed analysis of the test results. You can choose to
view either the current results (i.e. results measured during one second) or the
total results from measurement start. You can also zoom in on a specific result
item. The results can be displayed either in table (list) form or as a graph.
Selecting which results to viewSelecting which results to view
Touch the TotalTotal button to switch the total values measured in all interval times.
The start time of measurement is displayed on the button.
Touching the button in left side BackBack field shows the measured values in the
interval time. The end time of the interval is displayed on the button.
CurrentCurrent button is displayed at left bottom when the measurement is running.
Touching the CurrentCurrent button shows the measured values in the current interval
time. The start time of the current interval is displayed on the button.
