Auto FunctionsAuto Functions
Test ProfileTest Profile
Select the observing fiber type. Limits which will be judged as "Pass" are shown
in tables.
In the following tables, "None" means that the fiber has no scratches or defects.
"No limit" means that there is no limit to the number of scratches or defects.
For example, "None >3 μm" the fiber has no scratches or defects which is
larger than 3 μm.
SM PC>45SM PC>45: Single Mode Fiber, Physical Contact, Return Loss is more than 45
dB.
Zone NameZone Name DefectsDefects ScratchesScratches
Core None None
Cladding
No limit <2μm
5 from 2 μm to 5 μm
None >5 μm
No limit ≤3μm
None > 3μm
Adhesive No limit No limit
Contact None ≥10 μm No limit
SM APCSM APC: Single Mode Fiber, Angled Physical Contact
Zone NameZone Name DefectsDefects ScratchesScratches
Core None ≤4
Cladding
No limit <2 μm
5 from 2 μm to 5 μm
None >5 μm
No limit
Adhesive No limit No limit
Contact None ≥10 μm No limit
SM PC>25SM PC>25: Single Mode Fiber, Physical Contact, Return Loss is more than 25
dB.
Zone NameZone Name DefectsDefects ScratchesScratches
Core
2 ≤3 μm
None > 3 μm
2 ≤3 μm
None > 3 μm
Cladding
No limit ≤2μm
5 from 2 μm to 5 μm
None >5 μm
No limit ≤3μm
3 > 3μm
Adhesive No limit No limit
Contact None ≥10 μm No limit
MM PC 62.5MM PC 62.5: Multi-Mode Fiber, Physical Contact, Core diameter 62.5 μm
Zone NameZone Name DefectsDefects ScratchesScratches
Core
4 ≤5 μm
None >5 μm
No limit ≤3μm
0 > 5μm
Cladding
No limit ≤2μm
5 from ≤2 μm to ≤5 μm
None >5 μm
No limit ≤5μm
0 > 5μm
Adhesive No limit No limit
Contact None ≥10 μm No limit
MM PC 50.0MM PC 50.0: Multi-Mode Fiber, Physical Contact, Core diameter 50 μm
Limits are the same as MM PC 62.5MM PC 62.5.
Auto MeasurementAuto Measurement
