Status, ResultsStatus, Results
User-defined VLAN ID and VLAN priority
Address
Configurable IP and Ethernet source and destination addresses (supports
IPv4 and IPv6 addressing). Fixed, DHCP, DNS.
Flow control
Generate pause frames
Respond to pause frames
ARP
Answer incoming ARP request On/Off
IP
Fixed or incremented IP identifier
User programmable DSCP/TOS byte
UDP/TCP
User programmable UDP/TCP address
UDP Checksum: automatic or fixed (null)
TCP checksum: automatic
Status
Link status, RF, Signal present, Jabber detected, Frames present, Speed, Full
or half duplex, Interface type, Local clock (Ethernet 1000), Pause capable and
Asymmetric pause request (excluding 10Gbps), Link partner capabilities
(excluding 10Gbps)
Resolution
User-defined resolution for statistical measurements:
1, 2, 5, 10, 15, 30s, 1, 5, 15, 30 minutes, 1, 2, 4, 6, 12 hours.
Performance statistics
Maximum/Minimum/Average utilization
Maximum/Minimum/Average user and total throughput
Maximum/Minimum/Average frame rate
Maximum/Minimum/Average frame latency
Maximum/Minimum/Average packet jitter
Frame statistics
Total frames
Total valid frames
Unicast/multicast/broadcast frames
Pause frame
VLAN frame
MPLS frames
MPLS-TP frame
PBB frame
VLAN Max/Min level
MPLS Max/Min level
