Faults and Changes in grand-master clock
IEEE 1588 messages can be captured and exported in a Wireshark compatible
format.
Terminology
SDH, SONET
Supported encapsulations (frame formats)
EtherType ll (DIX v.2)
IEEE 802.3 with 802.2 (LLC1)
IEEE 802.3 with SNAP
Variable line rate traffic generation
Up to full line rate
Transmitter Frame size
From 44 bytes to 16,000 bytes
Receiver settings
User-defined expected preamble length (3 to 15 bytes)
User-defined IFG lower threshold * (8 to 15 bytes)
User-defined Jumbo frame size upper limit (1519 to 16000 bytes)
*: Only for Ethernet 10/100/1000 Mbps (cannot use 10Gbps)
Line load profile
Constant: 0.0008% - 100%
Ramp:
Line load: start, end, step (0.0001% resolution)
Duration: 3 to 3600 seconds
Ramp mode: Keep end line load, Repeat ramp, Invert ramp
Frame size profile
Constant
Stepped:
Frame size: start, end, step (to 16000 bytes)
Duration: 1 to 3600 seconds
Random:
Frame size: start, end (to 16000 bytes),
User-defined TCP/UDP frame size upper limit (2048 bytes)
Traffic duration
Continuous
Seconds: 1 to 2,000,000,000
Frames: 1 to 2,000,000,000
Unicast/broadcast
User-defined traffic mix of unicast and broadcast frames
VLAN
