IP Channel StatisticsIP Channel Statistics
One-way (uni- or bi-directional, symmetrical or asymmetrical)
Round-trip
Service Configuration Test:
With subtests for:
Committed Information Rate
Excess Information Rate
Traffic Policing
Committed Burst Size
Excess Burst Size
Step duration: 1 sec to 60 sec (user programmable)
Number of steps: 1 to 10 (user programmable)
Slope: rising or falling
Results:
Pass/Fail indication
IR (Maximum/Minimum/Average)
FL (Count/FLR)
FTD and FDV (Maximum/Minimum/Average/Current (during
measurement))
Service Performance Test:
All services tested simultaneously at CIR
Duration: 15 minutes, 2 hours, 24 hours or customer programmable
Results:
Pass/Fail indication
IR (Maximum/Minimum/Average)
FL (Count/FLR)
FTD and FDV (Maximum/Minimum/Average/Current (during
measurement))
AVAIL (%)
Unavail (sec)
Verification against Service Acceptance Criteria:
Information Rate
Frame Transfer Delay
Frame Delay Variation
Frame Loss Rate
Availability
IP Channel Statistics is available when the interface bit rate is 10Gbps or less.
Number of channels
The statistics are provided for up to 230 channels, identified by user-defined
combinations of:
IPv4, IPv6 or MAC address
VLAN ID or MPLS label
Protocol information
IP next header (protocol)
TPC/UDP ports.
Statistics
