RFC2544 installationRFC2544 installation
and commissioningand commissioning
RFC6349 TCPRFC6349 TCP
throughput testthroughput test
Service ActivationService Activation
Test (Y.1564)Test (Y.1564)
Frames and bytes received
Frames and bytes transmitted
Throughput
Latency/Jitter
Switch/router test and Single ended network test modes:
Throughput
Frame loss
Latency or packet jitter
Back-to-back frames (burstability)
End-to-end network test mode (two Network Master Pros in a master-slave
setup)
Throughput
Frame loss
Back-to-back frames (burstability)
Router latency test mode: IP ping based latency test or packet jitter.
For RFC2544 throughput measurement the user can choose to make the
measurement for:
Physical layer
Physical layer excl. preamble
Link layer
Network layer
Data layer
Average or maximum values
Supports connecting to iPerf server.
Test Direction Setup
Local -> Remote
Remote -> Local
Simultaneous in Both Direction
For RFC6349 test sequence the user can choose to make the measurement for:
Path MTU
Baseline RTT
Window Scan and Throughput
Multi-Service
Multi-Service: DSCP or TOS can be set to each TCP connections.
Destination Port
DSCP or TOS
Service Activation Test is an out-of-service test to assess the proper
configuration and performance of Ethernet services.
Test up to 8 services
Color-Aware and Non-Color-Aware in combinations (IP DSCP or VLAN PCP)
GPS timing synchronization
Two test modes:
