Ethernet MPLSEthernet MPLS
Ethernet MultistreamEthernet Multistream
Status
Indicator for detection of VLAN tagged frames
Statistics
Number of VLAN tagged frames
Maximum number of VLAN layers detected
MPLS supported
MPLS unicast is supported (EtherType 0x8847).
Support for MPLS in BERT, RFC 2544 (excluding router latency) tests and
general statistics
Number of MPLS headers
Up to 8 MPLS headers can be set by the user.
Parameters per MPLS header
User-defined label, Exp and TTL fields in each MPLS header
MPLS-TP support
PWE (Pseudo Wire Emulation Edge-to-Edge) label (the RFC4448 control word)
can be added.
Status
Indicator for detection of MPLS frames and MPLS-TP
Statistics
Number of MPLS frames and MPLS-TP frames
Maximum number of MPLS layers detected
Number of streams
Up to 16 streams can be activated on the Ethernet line.
Parameters per stream
Encapsulation (frame format)
Line rate traffic load, up to full line rate
Configurable IP and Ethernet source and destination addresses (supports
IPv4 and IPv6 addressing)
User-defined traffic mix of unicast and broadcast frames
Adjustable frame size from 44 bytes to 16000 bytes
Frame sizes may be set to constant, stepped or random length.
User programmable VLAN ID and VLAN priority
User programmable DSCP/TOS byte
User programmable UDP/TCP address
In stream 1 a BER test can be made.
Statistics
Available information per stream:
Frame loss count/rate
