ThroughputThroughput
measurementmeasurement
Service disruptionService disruption
measurementmeasurement
Ping testPing test
TracerouteTraceroute
Ethernet OAM optionEthernet OAM option
VLANVLAN
Framed with Ethernet (MAC) header and IP header (layer 3)
Framed with Ethernet (MAC) header, IP header and UDP/TCP header (layer 4)
Test patterns:
PRBS 9, PRBS 11, PRBS 15, PRBS 20, PRBS 23, PRBS 29, PRBS 31, HF test
pattern, CRPAT, JTPAT, SPAT
User-defined up to 32 bits. Length in step of 1 bit.
Detection of sequence errors and loss of sequence synchronization.
Frame loss count and frame loss seconds.
Throughput measurement: Maximum/Minimum/Average values are presented.
Test resolution
User-defined up to resolution:
1, 2, 5, 10, 15, 30 sec, 1, 5, 10, 15, 30 minutes, 1, 2, 4, 6, 12 hours
No intervals
Throughput may be calculated on 6 different layers:
Utilization layer
Physical layer
Physical layer excl. preamble
Link layer
Network layer
Data layer
Can be activated as part of the BER test:
Maximum/Average service disruption time, resolution 0.1 μsec
Number of service disruptions
For the connectivity check through the network.
Round Trip Time (RTT)
Supports IPv4 addressing
Answer incoming Ping requests (On/Off)
Trace the IP route over the IP network.
User-defined max no. of hops (1 to 255)
Information per hop: Maximum/Minimum/Average ping time and number of
ping timeouts
Y.1731 (Service Layer OAM)
IEEE 802.1ag (Connectivity layer OAM) and IEEE 802.3ah (Access Link OAM)
Number of VLAN tag
Up to 8 layers of VLAN can be inserted into the Ethernet frame.
Only 1 level of VLAN is supported in ping, Traceroute and RFC2544 router
latency tests.
Parameters per VLAN tag
EtherType 0x8100 (802.1Q), 0x88a8 (802.1ad), 0x9100 or 0x9200
User-defined VLAN ID, CFI and VLAN priority
