MeasurementMeasurement
ParameterParameter
SDH MappingsSDH Mappings
Dummy channelDummy channel
handlinghandling
Test patternsTest patterns
STM-4/OC-12
STM-16/OC-48
STM-64/OC-192
For bit rate, refer to Bit Rate of MU100010A.
Interval
1s, 2s, 5s, 10s, 15s, 30s,
1minute, 5minutes, 10minutes, 15minutes, 30minutes,
1hour, 2hours, 4hours, 6hours, 12hours,
No intervals
Start Key Action
Immediate
Start at(year-month-day, hour-minute-second)
Stop Function
Manual Stop
Stop at (year-month-day, hour-minute-second)
Duration (1second to 99days 23hour-59minute-59second )
1111..55..22..11 SDHSDH
STM-64 - AU4-64c - VC4-64c - Bulk
STM-64/STM-16 - AU4-16c - VC4-16c - Bulk
STM-64/STM-16/STM-4 - AU4-4c - VC4-4c - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-4 - VC-4 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-4 - VC-4 - E4
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-4 - VC-4 - TU-3 - VC-3 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-4 - VC-4 - TU-3 - VC-3 - DS3
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-4 - VC-4 - TU-3 - VC-3 - E3
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-4 - VC-4 - TU-12 - VC-12 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-4 - VC-4 - TU-12 - VC-12 - E1 (Async/Sync)
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-4 - VC-4 - TU-11 - VC-11 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-4 - VC-4 - TU-11 - VC-11 - DS1 (Async/Sync)
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - DS3
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - E3
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - TU-12 - VC-12 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-3 - VC-3 - TU-12 - VC-12 - E1 (Async/Sync)
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - TU-11 - VC-11 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-3 - VC-3 - TU-11 - VC-11 - DS1 (Async/Sync)
Copy, Unequipped (For AU only)
PRBS: 2
9
-1, 2
11
-1, 2
15
-1, 2
20
-1, 2
23
-1, 2
29
-1,2
31
-1 (Normal/Inverse)
Fixed :User Pattern, All0, All1, Alternating 1:1, Alternating 1:3, Alternating
1:7, 2 in 8
User Pattern : 32 bit, 2048 bit
