Tributary ScanTributary Scan
SONET MappingsSONET Mappings
Dummy channelDummy channel
handlinghandling
Test patternsTest patterns
Preset dataPreset data
VC-3 Allocation 0 to 100%
VC-11/VC-12 Allocation 0 to 100%
Time period : 15minutes, 1hour, 2hour, 24hour, 7days (only M.2101.1)
Result : ES, SES, BBE, UNAV
Display : Count, Ratio
Displays the alarm status of all channels in a specified layer.
Green (No alarm), Red (Alarm occurring), Gray (Not applied)
1111..55..22..22 SONETSONET
OC-192 - STS-192c - STS-192c SPE - Bulk
OC-192/OC-48 - STS-48c - STS-48c SPE - Bulk
OC-192/OC-48/OC-12 - STS-12c - STS-12c SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - E4
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - DS3
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - E3
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-12 - VT-12 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-12 - VT-12 SPE - E1 (Async/Sync)
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-11 - VT-11 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-11 - VT-11 SPE - DS1 (Async/Sync)
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - DS3
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - E3
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-12 - VT-12 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-12 - VT-12 SPE - E1 (Async/Sync)
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-11 - VT-11 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-11 - VT-11 SPE - DS1/J1 (Async/Sync)
Copy, Unequipped (For STS only)
PRBS: 2
9
-1, 2
11
-1, 2
15
-1, 2
20
-1, 2
23
-1, 2
29
-1,2
31
-1 (Normal/Inverse)
Fixed :User Pattern, All0, All1, Alternating 1:1, Alternating 1:3, Alternating
1:7, 2 in 8
User Pattern : 32 bit, 2048 bit
OH Preset data
TOH : All bytes except B1, B2, H1, H2 and H3 byte
STS-3c/STS-1 POH : All bytes except B3
VT-2/VT-1.5 POH : All bytes except BIP-2
Measurement FunctionalityMeasurement Functionality
