Through ModeThrough Mode
APSAPS
Delay measurementDelay measurement
SDH PerformanceSDH Performance
MeasurementMeasurement
Transceiver Information
Alarm, Wavelength and bit rate, Compliance, Vendor Information, Output
Control
Power monitor
MDIO analysis
For CFP4:
NVR1, NVR2, Module FAWS, MW Lane FAWS, CTRL, MDIO Read/Write
I2C analysis
For QSFP+ and QSFP28:
Lower, Lower (Lane), Upper (00), Upper (03), Read/Write
Setting
VOD, Pre, Post, DFE, Insertion loss
Mode :
Through Rx
OH Overwrite
SOH, A1/A2, K1/K2, S1, DCC1-3, DCC4-12, J0, SOH 1byte
Stimuli
Alarm : LOS, LOF, OOF, MS-RDI
Available alarms depend on Through mode setting.
Error : A1A2, B1, B2, MS-REI, ERR-TRANS
Available errors depend on Through mode setting.
Insertion: refer to Alarm Insertion and Error Insertion
APS (Automatic Protection Switching) Measurement
Reference event: LOS, LOF, OOF, MS-AIS, MS-RDI, APS Switchover, AU-AIS,
AU-LOP, HP-TIM, HP-PLM, HP-UNEQ, TU-LOM, TU-AIS, TU-LOP, LP-TIM, LP-
PLM, LP-UNEQ, LSS, A1A2, B1, B2, MS-REI, B3, V5, Pattern errors
Max reference duration: 0.000 to 10000.000 ms
Result: Average switching time, Maximum switching time, Minimum switching
time
APS Protocol analyze
APS configuration :Ring or Linear
Ring : Short Path, Long Path
Linear : 1+1 architecture, 1:n architecture
APS Protocol Request : The value of K1, K2 byte is sent depending on selected
type.
APS Interpretation : Number, Elapsed Time
Measurement Mode : Single, Repeat
Measurement Period : 0.5, 1, 2, 5,10 s
Measurement Range : Up to 10 000 000.000 μs / resolution 0.1 μs, Timeout
Setup : G826, G.828+G.829, M.2101.1(M2100)
Allocation
Mux Allocation 0 to 100%
VC-4 Allocation 0 to 100%
