Touch this icon to close the application.
Expanded Application toolbarExpanded Application toolbar
The
Application toolbar
is expanded/collapsed by touching the tab placed
above the left-most column. The column displayed in the expanded toolbar
contains the following functions:
Restart TestingRestart Testing
Touch this icon to restart the current test.
Load SaveLoad Save
Touch this icon to open Load/Save dialog box. You can load or save Setup file or
Result file. Only files matching the current application type are selectable for
loading.
When loading setup files, the number of port resources enclosed in the file has to match
that of the current application.
When loading result files, the exact physical ports enclosed in the file has to match that
of the current application.
Apart from actual results, result files also contain settings sampled at the time the test
was performed. When loading result files these settings will overwrite current application
settings.
Loading result files into a viewer will not take up port resources on the system. This is
practical if you only want to review previous results and don't need to run test again.
From the Result File Browser, select the result file you want to view and touch the View
icon ( ) at right hand top of the screen.
Stimuli setupStimuli setup
Various fields and buttons are available for setting up a stimulus signal to
provoke a special or abnormal situation during the test. When the signal has
been specified, the stimulus is sent by touching the Alarm/Error InsertAlarm/Error Insert icon (
).
The stimulus signal is sent via the transmitter, and the received signal can
simultaneously be inspected as a related status or result display. This allows to
evaluate the behavior of the device under test.
