About the SDS Enterprise Database Feature
Applied Biosystems 7900HT Fast Real-Time PCR System and SDS Enterprise Database User Guide 1-23
LAN Architecture Example
In a basic configuration, the SDS Enterprise Database can serve up to four DHCP or
TCP/IP clients configured in a star topography. In this configuration, the server is
linked to the clients via the router provided with the database which has been
configured with a static IP address.
Note: The router features a WAN connection for connecting to an external bus.
Figure 1-14 Basic LAN Architecture for the SDS Enterprise Database
