CLICK PLC Discrete Input Module ZIPLink Selector
I/O Module ZIPLink
Input Module Terminals Component Module Part No. Cable Part No.
C0-08SIM Not supported by ZIPLink
C0-08ND3
11 Feedthrough ZL-RTB20 ZL-C0-CBL11*
C0-08ND3-1
C0-08NE3
C0-08NA
C0-16ND3
20
Feedthrough ZL-RTB20
ZL-C0-CBL20*
Sensor ZL-LTB16-24-1
C0-16NE3
Feedthrough ZL-RTB20
Sensor ZL-LTB16-24-1
* Select the cable length by replacing the * with: Blank = 0.5 m, -1 = 1.0 m, or -2 = 2.0 m.
CLICK PLC Discrete Output Module ZIPLink Selector
I/O Module ZIPLink
Output Module Terminals Component Module Part No. Cable Part No.
C0-08TD1
11 Feedthrough ZL-RTB20 ZL-C0-CBL11*C0-08TD2
C0-08TR
C0-08TR-3 Not supported by ZIPLink
C0-08TA 11 Feedthrough ZL-RTB20 ZL-C0-CBL11*
C0-16TD1
20
Feedthrough ZL-RTB20
ZL-C0-CBL20*
Fuse ZL-RFU20
2
Relay (sinking) ZL-RRL16-24-1
C0-16TD2
Feedthrough ZL-RTB20
Fuse ZL-RFU20
2
Relay (sourcing) ZL-RRL16-24-2
C0-04TRS
1
Feedthrough ZL-RTB20
C0-04TRS-10 Not supported by ZIPLink
1
NOTE: The C0-04TRS relay output is derated not to exceed 2A per point max. when used with the
ZIPLink wiring system.
2
NOTE: Fuses (5 x 20 mm) are not included. See Edison Electronic Fuse section for (5 x 20 mm)
fuse. S500 and GMA electronic circuit protection for fast-acting maximum protection. S506 and
GMC electronic circuit protection for time-delay performance. Ideal for inductive circuits.
To ensure proper operation, do not exceed the voltage and current rating of ZIPLink module.
ZL-RFU20 = 2A per circuit.
* Select the cable length by replacing the * with: Blank = 0.5 m, -1 = 1.0 m, or -2 = 2.0 m.
ZIPLink Wiring System Compatibility Matrix for CLICK PLCs (continued)
CLICK PLC Hardware User Manual, 5th Edition, Rev. F – C0-USER-M
3–23
Chapter 3: Installation and Wiring
