AutomationDirect CLICK Series User Manual

CLICK PLC Analog I/O Module ZIPLink Selector
I/O Module ZIPLink
Analog Module # of Terms Component Module Part No. Cable Part No.
C0-04AD-1 11
Feedthrough ZL-RTB20 ZL-C0-CBL11*
C0-04AD-2 11
C0-04RTD 20
No ZIPLinks are available for RTD and thermocouple
modules.
C0-04THM 11
C0-04DA-1 11
Feedthrough ZL-RTB20
ZL-C0-CBL11*
C0-04DA-2 11 ZL-C0-CBL11*
C0-4AD2DA-1 20 ZL-C0-CBL20*
C0-4AD2DA-2 20 ZL-C0-CBL20*
* Select the cable length by replacing the * with: Blank = 0.5m, -1 = 1.0m, or -2 = 2.0m.
CLICK PLC Combo I/O Module ZIPLink Selector
I/O Module ZIPLink
Combo Module # of Terms Component Module Part No. Cable Part No.
C0-16CDD1
20
Feedthrough ZL-RTB20
ZL-C0-CBL20*
C0-16CDD2
C0-08CDR 11 ZL-C0-CBL11*
* Select the cable length by replacing the * with: Blank = 0.5m, -1 = 1.0m, or -2 = 2.0m.
ZIPLink Wiring System Compatibility Matrix for CLICK PLCs (continued)
CLICK PLC Hardware User Manual, 5th Edition, Rev. F – C0-USER-M
3–24
